Save image from RDD Apache Spark system
I want to retrieve the images that I have stored on my RDD system after I map them.
I created a simple Spark Session on my main.py
file which calls the function preprocess_spark that returns an array of tuples named samples
. These tuples are in the (slide_num, image)
format. Image is an np.array
that will be converted to an image in the save_jpeg_help
function.
When I open the Apache Spark WEB UI I see that it has a job corresponding to the line:
rdd.foreach(lambda sample_element: save_nonlabelled_sample_2_jpeg(sample_element, save_dir))
but when it finishes nothing is ever saved on my save_dir
directory.
Any idea what I'm doing wrong?
Kind regards
main.py
spark = (SparkSession.builder
.appName("Oncofinder -- Preprocessing")
.getOrCreate())
samples = preprocess_spark(spark, [1])
if save_jpegs: #SET TO TRUE
save_rdd_2_jpeg(samples, './data/images')
def save_rdd_2_jpeg(rdd, save_dir):
rdd.foreach(lambda sample_element: save_nonlabelled_sample_2_jpeg(sample_element, save_dir))
def save_nonlabelled_sample_2_jpeg(sample, save_dir):
slide_num, img_value = sample
filename = '{slide_num}_{hash}.jpeg'.format(
slide_num=slide_num, hash=np.random.randint(1e4))
filepath = os.path.join(save_dir, filename)
save_jpeg_help(img_value, filepath)
def save_jpeg_help(img_value, filepath):
dir = os.path.dirname(filepath)
os.makedirs(dir, exist_ok=True)
img = Image.fromarray(img_value.astype(np.uint8), 'RGB')
img.save(filepath)
def preprocess_spark(spark, slide_nums, folder="data", training=False, tile_size=1024, overlap=0,
tissue_threshold=0.9, sample_size=256, grayscale=False, normalize_stains=True,
num_partitions=20000):
slides = (spark.sparkContext
.parallelize(slide_nums)
.filter(lambda slide: open_slide(slide, folder, training) is not None))
tile_indices = (slides.flatMap(
lambda slide: process_slide(slide, folder, training, tile_size, overlap)))
tile_indices = tile_indices.repartition(num_partitions)
tile_indices.cache()
tiles = tile_indices.map(lambda tile_index: process_tile_index(tile_index, folder, training))
filtered_tiles = tiles.filter(lambda tile: keep_tile(tile, tile_size, tissue_threshold))
samples = filtered_tiles.flatMap(lambda tile: process_tile(tile, sample_size, grayscale))
if normalize_stains:
samples = samples.map(lambda sample: normalize_staining(sample))
return samples
EDIT: I'm using
PYSPARK_PYTHON=python3 spark-submit --master spark://127.0.1.1:7077 spark_preprocessing.py
to run the application. It seems that after the foreach
action, nothing else happens. Is there any reason for that?
python apache-spark pyspark
add a comment |
I want to retrieve the images that I have stored on my RDD system after I map them.
I created a simple Spark Session on my main.py
file which calls the function preprocess_spark that returns an array of tuples named samples
. These tuples are in the (slide_num, image)
format. Image is an np.array
that will be converted to an image in the save_jpeg_help
function.
When I open the Apache Spark WEB UI I see that it has a job corresponding to the line:
rdd.foreach(lambda sample_element: save_nonlabelled_sample_2_jpeg(sample_element, save_dir))
but when it finishes nothing is ever saved on my save_dir
directory.
Any idea what I'm doing wrong?
Kind regards
main.py
spark = (SparkSession.builder
.appName("Oncofinder -- Preprocessing")
.getOrCreate())
samples = preprocess_spark(spark, [1])
if save_jpegs: #SET TO TRUE
save_rdd_2_jpeg(samples, './data/images')
def save_rdd_2_jpeg(rdd, save_dir):
rdd.foreach(lambda sample_element: save_nonlabelled_sample_2_jpeg(sample_element, save_dir))
def save_nonlabelled_sample_2_jpeg(sample, save_dir):
slide_num, img_value = sample
filename = '{slide_num}_{hash}.jpeg'.format(
slide_num=slide_num, hash=np.random.randint(1e4))
filepath = os.path.join(save_dir, filename)
save_jpeg_help(img_value, filepath)
def save_jpeg_help(img_value, filepath):
dir = os.path.dirname(filepath)
os.makedirs(dir, exist_ok=True)
img = Image.fromarray(img_value.astype(np.uint8), 'RGB')
img.save(filepath)
def preprocess_spark(spark, slide_nums, folder="data", training=False, tile_size=1024, overlap=0,
tissue_threshold=0.9, sample_size=256, grayscale=False, normalize_stains=True,
num_partitions=20000):
slides = (spark.sparkContext
.parallelize(slide_nums)
.filter(lambda slide: open_slide(slide, folder, training) is not None))
tile_indices = (slides.flatMap(
lambda slide: process_slide(slide, folder, training, tile_size, overlap)))
tile_indices = tile_indices.repartition(num_partitions)
tile_indices.cache()
tiles = tile_indices.map(lambda tile_index: process_tile_index(tile_index, folder, training))
filtered_tiles = tiles.filter(lambda tile: keep_tile(tile, tile_size, tissue_threshold))
samples = filtered_tiles.flatMap(lambda tile: process_tile(tile, sample_size, grayscale))
if normalize_stains:
samples = samples.map(lambda sample: normalize_staining(sample))
return samples
EDIT: I'm using
PYSPARK_PYTHON=python3 spark-submit --master spark://127.0.1.1:7077 spark_preprocessing.py
to run the application. It seems that after the foreach
action, nothing else happens. Is there any reason for that?
python apache-spark pyspark
1
Are you running this on a single node or multiple nodes? Are you using a relative path or an absolute path?
– ayplam
Nov 28 '18 at 7:59
1
Given that you're running this on multiple nodes, you definitely cannot just callimg.save(filepath)
and expect it to work like it would in normal Python execution. Lord only knows where on your cluster your image files are actually ending up. Instead, you'll have tocollect
the image arrays on the driver node and only then runImage.fromarray
andimg.save
on those arrays.
– tel
Dec 8 '18 at 4:04
I triedrdd.collect().foreach(...)
instead ofrdd.foreach(...)
but I getlist object has not attribute foreach
– Luís Costa
Dec 8 '18 at 6:29
rdd.collect()
will return a standard Pythonlist
. You would then have to iterate over the contents of that list and call your image saving function on each element. See my answer below for more details.
– tel
Dec 9 '18 at 2:15
